SOLIDWORKS MBD

Define, organize, and publish 3D annotations, including 3D model data in industry-standard file formats.

Why Choose SOLIDWORKS MBD?

SOLIDWORKS® Model-Based Definition (MBD) lets you define and organize 3D dimensions, tolerances, datums, notes, Bills of Material (BOMs), and other annotations; customize publishing templates for manufacturing, such as Part or Assembly Specifications, Request for Quote (RFQ), and Incoming Inspection Reports. You can also publish to widely accepted formats, such as eDrawings®, STEP 242, and 3D PDF for clear 3D communications.

For easier adoptions of the model-based practices, several convenient capabilities have been included in every seat of SOLIDWORKS Standard. With SOLIDWORKS Standard, you can annotate a 3D part or assembly, organize the 3D definitions with annotation views and communicate in eDrawings all directly in 3D.

SOLIDWORKS MBD

SOLIDWORKS MBD helps you define feature-based annotations in Parts and assemblies (DimXpert), and import 3D annotations from common CAD formats for more efficient design.

When the number of 3D annotations becomes too many, you can show and hide annotations automatically as a model rotates, capture comprehensive settings with 3D views similar to visual bookmarks, compare 3D annotation differences between revisions to capture subtle but critical differences, and reuse 3D views in 2D drawings when necessary.

SOLIDWORKS MBD helps you communicate directly in 3D. If you like 3D PDF, the software can customize the templates, control accuracies and PDF sizes, publish BOM tables and notes, attach multiple files upon publishing, create and attach STEP242 files. SOLIDWORKS MBD can also output eDrawings or STEP 242 with software-readable annotations.

Unlike miscommunications in 2D drawings and manufacturing based on dated 2D drawings, SOLIDWORKS MBD facilitates 3D engineering communication with integrated 3D specifications, greater clarity, reduced ambiguity, and a shorter update path.

SOLIDWORKS MBD adds clarity in manufacturing communication with 3D integrated specifications, which can also drive downstream applications automatically, such as CAM and CMM programming. SOLIDWORKS MBD enables 3D annotations beyond geometry-based programming.

SOLIDWORKS MBD defines and organizes intuitive 3D specifications integrated with models, which shortens the learning curve. The output of high-quality STEP 242 and 3D PDF complies with the Long Term Archival and Retrieval (LOTAR) standard.

Have questions about SOLIDWORKS MBD?

GDS Middle East is a leading Authorized Reseller for SOLIDWORKS MBD in UAE and Saudi Arabia. We have sales & technical support offices in UAE and Saudi Arabia. We can help you invest in your future by learning the SOLIDWORKS MBD.

If you are looking for SOLIDWORKS MBD, take the next step. With SOLIDWORKS MBD, we can define, organize, and publish 3D annotations, including 3D model data in industry-standard file formats. Get in touch with GDS Middle East today.
