SWOOD Nesting

Achieve efficient nesting with SWOOD CNC Nesting, reducing material costs and environmental impact.

Optimize CNC Nesting Process

CNC nesting software to nest and optimize project parts onto a wood panel to reduce material waste. SWOOD Nesting is a bolt-on to SWOOD CAM.

A complete CNC nesting software

Nesting from 3D Models

Nest 3D models to optimize raw material. SWOOD Nesting allows you to accurately nest your project’s parts onto wood panels for manufacture and optimise output with several strategies.

Combine multiple projects and materials

Add multiple source files, from simple cabinets to complex free-form shapes, with different thicknesses and materials to optimize Nesting sheets.

Grain matching on panels

Linked to SWOOD Design, SWOOD Nesting can match the grain direction of furniture front panels for aesthetic finishing. These front panels are then grouped as a single entity, thus making it possible to nest them together (front grouping).

Optimal holding

With these features, you can optimize the holding process of a nesting board:

  • Cutting order (from the smallest to the largest part);
  • Optimized trajectories to let material as long as possible on the part;
  • Automatic bridges / staples insertion between nested parts;
  • Avoid small parts close to board edges.

Manual nesting

With SWOOD Nesting, it is possible to:

  • Modify the position of automatically defined parts;
  • Add trajectory jumps (bridges);
  • Modify the machining order of parts;
  • Modify the entry point (lead in/lead out);
  • Modify numbering (labels).

Reporting

SWOOD Nesting enables the automatic creation of workshop documents with nesting sheet lists, programs, bills of material, and labels in different formats such as : .HTML, .EXCEL, .PDF, and other related formats.

CNC nesting software to reduce waste

Reduce raw material loss

SWOOD Nesting allows nesting all the parts of a project to optimize the raw material. Moreover, the manual nesting feature can move the parts in case of damage to a part of the nesting sheets.

Complete Integration

Since all SWOOD solutions are interconnected, changes made in the design area are automatically reflected in the manufacturing area. The CNC machine programs can therefore be updated, as well as the associated Nesting programs.

More Efficient

It is much easier to hold small parts in position on CNC nesting machines compared to a conventional suction cup machine. Machining cycles are also reduced because the operator does not have to reload the machine for each part.

Time-Saving

With the nesting module, replace the need to saw the panels before starting the machining of the parts. All contouring and 3-axis machining is done directly on the CNC nesting machine.
